Plan 20050GA
Craftsman House Plan Gem
Heated S.F.
2,964
Beds
4
Baths
4
Stories
2
Cars
3
What's Included
Plan Details
  • A spacious front porch bids you welcome to this 4 bedroom craftsman house plan gem. The foyer provides direct access to an exquisite dining area and a sizeable quest suite.
  • The grand two-story family room is open to the gourmet kitchen/breakfast area as well as the dramatic hearth room. A home office is conveniently located off the breakfast nook. Also accessible from this area is a screened porch.
  • In addition to the stairs, an elevator provides access to the upper level with its 2 bedrooms with en-suite baths plus a grand master suite. A convenient mini-kitchen services this floor. The laundry room is also located on this bedroom level.
  • The master suite features a vaulted ceiling and a his-and-hers walk-in closet with an expansion area available to virtually triple its size. With its soaking tub and separate shower, the luxurious master bath is the perfect place to unwind. Then relax with a cup of coffee on the private screened porch!
  • Completing this house plan plan is a 3-car garage with a side entry. A workshop featuring a utility sink is a handyman's delight.
  • Related Plans: Building in reverse? See house plan 20051GA.
  • For an alternate layout, see house plan 20048GA and 20049GA (reverse layout).
What's Included
  • Digital exterior rendering cover page
  • Exterior elevation page
  • Main floor plan page with electrical, 3-D floor plan, and window and door schedule
  • Upper level floor plan page with upper floor framing schematic, and 3-D floor plan
  • Cross sections and interior elevation page
  • Roof framing plan with 3-D roof framing schematic
  • IRC code specifications and methodologies
  • General construction details
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
