Detached Garage with Storage & Bonus

Plan 21901DR

  • 0

    Heated s.f.

  • 0

    Beds

  • 1-2

    Stories

  • 2

    Cars

  • This garage plan has 784 s.f. on the main level and 446 s.f. above for storage.
  • The garage doors are 10' x 7'.
  • Related Plans: For a slightly smaller version, see plan 21900DR. For a three car version, see plan 21902DR.

Each plan includes the following:

* 4 Elevations
* Foundation Plan
* Main Floor Plan
* Upper Floor Plans (if applicable)
* Roof Plan
* Truss Diagrams & Building Section
* Construction Details
* Typical Wall Section

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Detached Garage with Storage & Bonus - 21901DR floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Detached Garage with Storage & Bonus - 21901DR floor plan - 2nd Floor

Plan details

Plan Collections

Detached Garage with Storage & Bonus

  • 0

    Heated s.f.

  • 0

    Beds

  • 0

    Baths

  • 1-2

    Floors

  • 2

    Car garage

Buy This Plan
  • Reproducible Set $445
  • PDF - Single-Build $445
  • CAD + PDF - Single-Build $745
  • View all purchase option online

About This Plan

  • This garage plan has 784 s.f. on the main level and 446 s.f. above for storage.
  • The garage doors are 10' x 7'.
  • Related Plans: For a slightly smaller version, see plan 21900DR. For a three car version, see plan 21902DR.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 0 sq. ft.
  • Storage: 446 sq. ft.

Beds/Baths

  • Bedrooms: 0

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 28' 0"
  • Depth: 28' 0"
  • Max ridge height: 23' 1"

Garage

  • Type: Detached
  • Area: 784 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 6" Second Floor / 8' 0"

Roof

  • Framing Type: Truss
