Plan 15837GE
Five Bedrooms with Exterior Options
Heated S.F.
3,363
Beds
5
Baths
4
Stories
2
Cars
3
What's Included
Plan Details
  • This attractive Traditional home plan was designed with five bedrooms for the larger family.
  • Both the foyer and grand room are two-story for an open and airy feeling.
  • An eating bar in the kitchen is perfect for informal meals and a larger breakfast nook is set in a bay.
  • Guests will appreciate the first floor guest suite with its own bath.
  • Almost twenty feet long, the master suite has an elegant tray ceiling, large bath and huge walk-in closet.
  • Three more bedrooms can be found on the second floor along with a loft and unfinished bonus space.
  • Related Plans: Get a smaller living room and alternate exterior with house plans 15736GE.
    Get an expanded living room with house plan 15836GE.
What's Included
  • Exterior elevations: Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
  • Foundation Plan: Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
  • Detailed Floor Plans: These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
  • Interior Details: These drawings show the specific details and design of special interior features.
  • Roof Plan: Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
  • Cross Section Detail: Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
  • Electrical: Electrical floor plan schematics for 1st and 2nd floors.
  • Plans include wall and cornice sections, general foundation sections and details.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Framing plans
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
