Plan 2530DH
Interesting Angles
Heated S.F.
2,293
Beds
3-4
Baths
3
Stories
1
Cars
3
What's Included
Plan Details
  • This home plan offers an angled snack bar in the kitchen with a large walk-in pantry. Arched openings accent the dining room from the kitchen and foyer.
  • Off the Foyer you'll find Bedroom 2 or a study/office. This room has a full bath, so you have options galore.
  • The master wing has a large walk-in closet and spa-style bath with a whirlpool tub tucked into an angled bay, dual sinks, a corner shower and a separate toilet compartment.
  • Bedrooms 3 and 4 share a Jack and Jill bath and each have their own linen area.
  • This home plan offers a large garage. It can be a two car garage with an extra bay for storage, a golf cart or a workshop area or if you have a smaller car make it a 3-car garage.
  • The rear covered porch is great for relaxing in the afternoon or with a cup of coffee off the angled breakfast area.
  • Related Plans: Get 4 bedrooms with these house plans - 2534DH, 2589DH and 2511DH.
What's Included
  • Floor plans - Included with your plans will be a detailed floor plan at 1/4" scale with a window and door schedule.
  • Foundation Plan - On many of our plans we offer you options on the type of foundation. The available options for each plan are shown on the page with the plans.
  • Electrical Plan - This sheet will show the locations of all lights, receptacles, switches, etc. as well as a roof layout.
  • Exterior Elevations - Our plans include complete front, sides and rear views, as well as any special exterior details.
  • Interior Elevations of cabinets, cabinet details, columns and walls with unique conditions.
  • Building Sections, Details and Typical Specifications Sheets
  • Some plans can be ordered with a materials list for an extra change. Please check availability for this option.
  • Plumbing diagrams and HVAC plans are not available for these homes, since they are generally not needed for home construction and since each county's code will vary and a licensed plumber and/or electrician must follow the codes.

What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
