Plan 65796BS

Luxury Coastal Contemporary House Plan with 6 Bedrooms and Courtyard Garage

Name: Plan 65796BS: Luxury Coastal Contemporary House Plan with 6 Bedrooms and Courtyard Garage
Brand: Architectural Designs
SKU: 65796BS
Price: 6591.0 USD
Availability: InStock

Heated S.F.

6,591

Beds

Baths

6.5+

Stories

Cars

Floor Plan

Plan Details

This expansive 6,591 square foot coastal contemporary estate features 6 bedrooms, 6 full baths, 2 half baths, and a 4-car courtyard garage.
The home greets guests with a sophisticated courtyard entry that leads into a grand, light-filled foyer designed for seamless movement.
A generous main living area anchors the home, featuring two kitchen islands and a walk-in pantry that caters to gourmet culinary needs.
The primary suite is situated on the main level for ultimate privacy and includes a dedicated sitting area for quiet mornings.
Additional lifestyle amenities include a private home office, a dedicated wine room, a wet bar, and a convenient elevator for multi-level access.
A massive 1,256 square foot lanai serves as the ultimate outdoor retreat, complete with an outdoor kitchen for alfresco dining and relaxation.
The upper level provides ample space for family and guests, including a finished bonus room that can serve as a media center or hobby space.

What's Included

Elevations: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Material Labels
Floor-To-Floor Heights
Roof Slope Indicators

Floor Plans: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Door and Window Sizes
Completely Dimensioned Floor Plan
Room Labels and Interior Room Sizes

Electrical Layouts:

Building Section Markers
All Electrical Outlets, Fixtures and Switching

Foundation or Slab Plan: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor and Deck Joist Sizes, Spacing and Direction
Electrical Locations

Roof Design Plan: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

All Beam and Header Heights and Locations
All Hips, Gables, Ridges and Valley
Building Section Markers

Building Sections: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor-To-Floor Heights
Non-Typical Plate Heights Indicated

Typical Wall Sections: - Drawn at 1/8″ to 1/2″ = 1’0″ Scale and Includes:

All Labels Indicating Wall Construction
Foundation Wall Thickness
Insulation Type and Thickness

Miscellaneous Notes and Details:

Miscellaneous General Notes
Stairway Details (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally, or use our structural engineering service if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

IMPORTANT NOTE: Structural drawings, as well as heating and plumbing details, will not be included in your plan sets due to a variety of factors which include local codes, installation methods, personal preference, etc. Your building professional (contractor/builder/supplier) can, without difficulty, supply these details and specifications on your behalf.
