Plan 80950PM

Northwest Multi-Level 2-Family House Plan

Heated S.F.
3,388
Units
2
Width
Depth

Floor Plan

Plan 80950PM

Main Level
Main Level
2nd Floor
2nd Floor

Plan 80950PM

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 80950PM: Northwest Multi-Level 2-Family House Plan - Floor Plan - Main Level - Modern, Northwest, Prairie

2nd Floor

Plan 80950PM: Northwest Multi-Level 2-Family House Plan - Floor Plan - 2nd Floor - Modern, Northwest, Prairie

Plan Details

  • Stone, brick, and horizontal siding adorn the exterior of this structure offering two separate units, each with three bedrooms and a 1-car garage.
  • The main level of each unit provides an open layout allowing conversation to flow comfortably between the kitchen, living, and dining rooms.
  • Upstairs, a second living room offers the resident flexibility, and three bedrooms share a bathroom with a separate tub and shower.
  • The laundry facilities are located on the second level for added convenience.
Unit A
Heated Area
1,694Sq. Ft.
720 Sq. Ft. 1st
974 Sq. Ft. 2nd
Beds
3Beds
Baths
1Full Bath
1Half Bath
Cars
Attached
254 Sq. Ft.
Dimensions
26'width
40'depth
31'height
Unfinished Areas
254 Sq. Ft. Garage
Unit B
Heated Area
1,694Sq. Ft.
720 Sq. Ft. 1st
974 Sq. Ft. 2nd
Beds
3Beds
Baths
1Full Bath
1Half Bath
Cars
Attached
254 Sq. Ft.
Dimensions
26'width
40'depth
31'height
Unfinished Areas
254 Sq. Ft. Garage

What's Included

Please note this plan is designed to the National Building Code of Canada.
  • Exterior Elevations – Four detailed exterior elevations views showing the final appearance of each side of the house.
  • Foundation Plans – Different isometric views with dimensions as well as relevant information to build the foundation.
  • Floor Plans – A drawing of each floor of the house. They are fully dimensioned showing the size of rooms and the location and size of windows, doors and staircases.
  • Cross-Section View – Vertical section of the house showing the structure, insulation, typical wall configuration as well as other details
  • The plans include the 4 elevations views, foundation plans, floor plans, cross section, staircase section, materials specifications and various construction details which aid in the house's construction.
  • The plan views, cross sections and front elevations are drawn to the scale of 1/4" = 1'-0"; the side and rear elevations are 1/8" = 1'-0" and some details are 1/2" = 1'-0".
  • Lintel, beam, post, footing sizes, etc. are calculated (may require local architect/ engineer stamp) and the plans are available in metric.

View Sample Plan

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

3,388 sq. ft.

1st Floor

1,440 sq. ft.

2nd Floor

1,948 sq. ft.

Beds/Baths

Bedrooms

6

Full bathrooms

2

Half bathrooms

2

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

52' 0"

Depth

40' 0"

Max Ridge Height

31' 0"

Garage

Type

Attached

Area

508 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9' 2"

Roof Details

Framing Type

Truss

Architectural Style

Modern

Northwest

Prairie

Special Features

Laundry - Upstairs

Master Suite - Upstairs

Plan Collections

Canadian House Plans

Metric

Square Footage Breakdown

Total Heated Area

3,388 sq. ft.

1st Floor

1,440 sq. ft.

2nd Floor

1,948 sq. ft.

Beds/Baths

Bedrooms

6

Full bathrooms

2

Half bathrooms

2

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

52' 0"

Depth

40' 0"

Max Ridge Height

31' 0"

Garage

Type

Attached

Area

508 sq. ft.

Count

2 Cars

Entry Location

Front

Ceiling Heights

First Floor

9' 2"

Roof Details

Framing Type

Truss

Architectural Style

Modern

Northwest

Prairie

Special Features

Laundry - Upstairs

Master Suite - Upstairs

Plan Collections

Canadian House Plans

Metric
