Plan 80520PM

Petite Castle

Heated S.F.

2,922

Beds

4

Baths

2.5

Stories

2

Cars

2

What's Included

Floor Plan

Main Level

Reverse Floor Plan

Petite Castle - 80520PM floor plan - Main Level

2nd Floor

Reverse Floor Plan

Petite Castle - 80520PM floor plan - 2nd Floor

Plan Details

A grand turret makes the exterior of this European home plan look like a castle.
An air lock foyer keeps the cold air out of the rest of the home.
A corner fireplace warms the large living room that opens to the dining room with pocket doors.
The efficient kitchen has a center island that adds extra counter space.
All of the bedrooms are on the second floor including the vaulted master suite.
The hall leading to the master suite is open on both sides so you can see the foyer below.

What's Included

Please note this plan is designed to the National Building Code of Canada.

Exterior Elevations – Four detailed exterior elevations views showing the final appearance of each side of the house.
Foundation Plans – Different isometric views with dimensions as well as relevant information to build the foundation.
Floor Plans – A drawing of each floor of the house. They are fully dimensioned showing the size of rooms and the location and size of windows, doors and staircases.
Cross-Section View – Vertical section of the house showing the structure, insulation, typical wall configuration as well as other details
The plans include the 4 elevations views, foundation plans, floor plans, cross section, staircase section, materials specifications and various construction details which aid in the house's construction.
The plan views, cross sections and front elevations are drawn to the scale of 1/4" = 1'-0"; the side and rear elevations are 1/8" = 1'-0" and some details are 1/2" = 1'-0".
Lintel, beam, post, footing sizes, etc. are calculated (may require local architect/ engineer stamp) and the plans are available in metric.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Square Footage Breakdown

Total Heated Area:

2,922 sq. ft.

1st Floor:

1,244 sq. ft.

2nd Floor:

1,678 sq. ft.

Beds/Baths

Bedrooms:

4

Full bathrooms:

2

Half bathrooms:

1

Foundation Type

Standard Foundations:

Basement

Need A Different Foundation?

Request A Modification Quote

Exterior Walls

Standard Type(s):

2x6

Dimensions

Width:

36' 0"

Depth:

54' 0"

Max Ridge Height:

39' 7"

Garage

Type:

Attached

Area:

419 sq. ft.

Count:

2 Cars

Entry Location:

Front

Ceiling Heights

Floor / Height:

First Floor / 9' 0" Second Floor / 8' 0"

Roof Details

Primary Pitch:

12 on 12

Framing Type:

Truss

Architectural Style

Special Features

Master Suite - 2nd Floor

Plan Collections
