Plan 420046WNT Rustic 1055 Square Foot Home Plan with Wraparound Porch

Rustic 1055 Square Foot Home Plan with Wraparound Porch

Plan 420046WNT

  • 1,055

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • A 5'-deep porch wraps around the front-right corner of this 3-bed rustic ranch home plan with 3 bedrooms.
  • Windows line the front, giving you great views from the living room. On the side wall, glass doors give you more views and open to the outdoors.
  • A C-shaped kitchen with walk-in pantry opens to the living room and has the sink perfectly placed below the window looking out back.
  • The bedrooms and two baths are clustered on the left of the home. A stackable washer and dryer are convenient to all.
  • Bed 1 has its own bathroom and access to a private covered porch in back.

What is Included in Our Plans?

Each plan is designed to meet nationally recognized building codes for the year they were created. Following is a listing of sheets included in our plans:

Foundation Plan

outlines details of the slab, crawl space, or basement specifically associated with the house that this plan has been designed for. These details may include; Footing sizes and locations, Floor framing information, Slab information etc.

Floor Plan

shows the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc. of each level of the house.

Exterior Elevations

show the front, rear and sides of the house, including exterior materials, details and roof pitches.

Building Cross Section

shows details of the house as though it were cut in slices from the roof to the foundation. The cross sections detail the construction of the home, insulation, flooring and roofing.


Roof Plan

provides a bird's eye view of the roof's valleys, ridges and dormers, if applicable

Electrical Plan (when available)

shows the suggested locations for fixtures and outlets. Please contact us to see if an electrical plan is included in the plan set.

Notes & Details

provides information for structural specifications, excavating and grading, masonry and concrete work, carpentry and wood specifications, thermal and moisture protection and specifications about drywall, tile, flooring, glazing, caulking and sealants.

What is not included in the plans:

  •           Architectural or Engineering Stamp
  •           Site Plan (available as an upgrade option)
  •           Mechanical Drawings (location of heating and air equipment and duct work)
  •           Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations)
  •           Framing layouts with beam sizes and locations
  •           Energy calculations

Building Code

Because of the wide range of requirements throughout states and municipalities, it is possible that the plans may not have all of the information required by your building department. If this is the case, we recommend hiring a local design professional or engineer who can assist bringing the plans up to your local building code.

Engineering

Some states require that a licensed architect or engineer review and stamp the plans. If this is the case where you will be building, a local professional will be able to assist you.

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rustic 1055 Square Foot Home Plan with Wraparound Porch - 420046WNT floor plan - Main Level

Plan details

Rustic 1055 Square Foot Home Plan with Wraparound Porch

  • 1,055

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

Buy This Plan
  • PDF - Single-Build $995
  • 5 Sets $1,145
  • 5 Sets + PDF $1,245
  • CAD - Unlimited Build $1,895
  • View all purchase option online

About This Plan

  • A 5'-deep porch wraps around the front-right corner of this 3-bed rustic ranch home plan with 3 bedrooms.
  • Windows line the front, giving you great views from the living room. On the side wall, glass doors give you more views and open to the outdoors.
  • A C-shaped kitchen with walk-in pantry opens to the living room and has the sink perfectly placed below the window looking out back.
  • The bedrooms and two baths are clustered on the left of the home. A stackable washer and dryer are convenient to all.
  • Bed 1 has its own bathroom and access to a private covered porch in back.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 1,055 sq. ft.
  • 1st Floor: 1,055 sq. ft.
  • Covered Patio: 346 sq. ft.
  • Porch, Combined: 346 sq. ft.
  • Porch, Rear: 84 sq. ft.
  • Porch, Front: 140 sq. ft.
  • Side Porch: 122 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Monolithic Slab, Slab
    • Optional Foundations: Crawl

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 44' 0"
  • Depth: 31' 0"
  • Max ridge height: 16' 9"

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 6 on 12
  • Secondary Pitch: 9 on 12
  • Framing Type: Truss
