Symmetrical Modern House Plan with Matching Wings and Large Outdoor Entertaining Space
Heated S.F.
3,642
Beds
4
Baths
4.5
Stories
1
Cars
4
Plan Details
  • The symmetrical layout of this 3,642 square foot 4 bed, 4.5 bath modern home plan gives you two wings, each with its own 2-car garage.
  • The center of the home provides wide sweeping views all the way from the grand entrance through glass French front doors through the wide-open great room, dining area, and kitchen out beyond the wall of windows to the magnificent outdoor living spaces.
  • The gourmet kitchen has a large island, seats four, with built-in sink.  Just steps away is a breakfast nook with large windows on 2 sides letting in the morning sunshine and providing views out over the pool. The large walk-in pantry has access from one of the garages for easy unloading of groceries.
  • The left side is dedicated to the master suite with a massive bathroom complete with soaking tub, sauna, accessible walk-in shower, and walk-in closet. A large office behind a pocket door and a laundry room complete the master wing.
  • The opposite wing is designed to house friends and family with 3 bedrooms and 3 bathrooms. A lounge shares a two-sided see-through fireplace with the great room on the other side. A home gym with vaulted ceiling completes the guest wing.
  • The expansive covered porch has three skylights, allowing for a deep and naturally brightly protected outdoor living space with summer kitchen, outdoor dining area, and lounge.
  • BUILDING RESTRICTION: This plan may not be built on Lake Norman, NC; Lake Wylie, NC; Mecklenburg Co. NC; Gaston Co. NC; Iredell Co. NC; Catawba Co. NC; Lincoln Co.; York Co. SC; Lancaster Co. SC.
What's Included
  • Foundation plan
  • Detailed floor plans
  • Roof plan
  • Elevations (all four sides)
  • Sections
  • 3D model views
  • Electrical plans
  • Framing details
What's Not Included
  • Electrical Plan - handled by your subcontractor to match your individual needs
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Symmetrical Modern House Plan with Matching Wings and Large Outdoor Entertaining Space

  • 3,642

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 1

    Floors

  • 4

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 3,642 sq. ft.
  • 1st Floor: 3,642 sq. ft.

Dimensions

  • Width: 100' 0"
  • Depth: 71' 4"
  • Max ridge height: 29' 11"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 1373 sq. ft.
  • Count: 4 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Combo Slab-Crawl

Exterior Walls

  • Standard Type(s): 2x4 and 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Roof

  • Primary Pitch: 4 on 12
  • Framing Type: Truss
