Plan 62497DJ Traditional Home Plan with Large Garage

2,478 2 2 1 3
Print
Compare
...

Traditional Home Plan with Large Garage

Plan 62497DJ

  • 2,478

    Heated s.f.

  • 2

    Beds

  • 2

    Baths

  • 1

    Stories

  • 3

    Cars

  • This is single story traditional house plan with an open kitchen and breakfast area with a fireplace.
  • The master has a tray ceiling and access to the back covered porch.
  • The great room has 12' ceilings and can be seen as you enter the home. An arched opening separates it from the kitchen with its curved counter and great views.
  • A 1,020 sq. ft. 3 car garage has tandem parking giving you room for a workshop or a fourth car.

Each plan set includes:


  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical Stair section
  • Cabinets are shown on all plans.

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Traditional Home Plan with Large Garage - 62497DJ floor plan - Main Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 2,478 sq. ft.
  • 1st Floor: 2,478 sq. ft.

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Basement
  • Optional Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 68' 0"
  • Depth: 66' 0"
  • Max ridge height: 24' 0"

Garage

  • Type: Attached
  • Area: 1020 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof Details

  • Primary Pitch: 6 on 12
  • Framing Type: Stick

Architectural Style

Special features

Plan Collections



Traditional Home Plan with Large Garage

  • 2,478

    Heated s.f.

  • 2

    Beds

  • 2

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $1,200
  • 5 Sets + PDF $1,450
  • PDF - Unlimited Build $1,700
  • CAD - Single-Build $1,700
  • CAD - Unlimited Build $2,200
  • View all purchase option online

About This Plan

  • This is single story traditional house plan with an open kitchen and breakfast area with a fireplace.
  • The master has a tray ceiling and access to the back covered porch.
  • The great room has 12' ceilings and can be seen as you enter the home. An arched opening separates it from the kitchen with its curved counter and great views.
  • A 1,020 sq. ft. 3 car garage has tandem parking giving you room for a workshop or a fourth car.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,478 sq. ft.
  • 1st Floor: 2,478 sq. ft.

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 68' 0"
  • Depth: 66' 0"
  • Max ridge height: 24' 0"

Garage

  • Type: Attached
  • Area: 1020 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Stick

Plan 62497DJ
View this and more for this plan by visiting www.architechtecturaldesigns.com/62497DJ
|
Need Help? 800-854-7852
|
Plan 62497DJ
