Plan 22674DR
Transitional 3 Bedroom Cottage with Home Office and Lower Level Family Room
Heated S.F.
2,248
Beds
1-3
Baths
2
Stories
1
What's Included
Plan Details
  • This transitional cottage gives you 3 beds, 2 baths and a total of 2,248 square feet of heated living spread across the main level and the finished lower level.
  • A closet in the foyer helps control clutter and an arched opening leads you to the open concept layout in back. Sliding doors on the back wall take you to a patio while the island in the kitchen gives you not only great workspace but also seating for up to five people.
  • In the back-right corner, a flex room makes a great work-from-home space.
  • The master suite is the only bedroom of the three on the main floor and with Beds 2 and 3 in the lower level sharing a bath. Laundry and a large family room complete the lower level.
What's Included
  • Elevations
  • Foundation Plan
  • Main Floor Plan
  • Upper Floor Plans (if applicable)
  • Roof Plan
  • Building Section
  • Construction Details
  • Typical Wall Section
Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Transitional 3 Bedroom Cottage with Home Office and Lower Level Family Room

  • 2,248

    Heated s.f.

  • 1-3

    Beds

  • 2

    Baths

  • 1

    Floors

Floor Plan

  • Main Level

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total: 2,248 sq. ft.
  • Lower Level: 1,124 sq. ft.
  • 1st Floor: 1,124 sq. ft.

Dimensions

  • Width: 37' 0"
  • Depth: 36' 0"
  • Max ridge height: 27' 8"

Beds/Baths

  • Bedrooms: 1, 2, or 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Slab, Monolithic Slab, Walkout, Daylight, Crawl

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Secondary Pitch: 10 on 12
