Transitional Country Home Plan Just Under 5,000 Square Feet

Plan 82291KA

  • 4,939

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 2

    Stories

  • 3

    Cars

  • A courtyard created by the protruding garage bays welcomes you to this Transitional Country home plan that gives you just under 5,000 square feet of living space.
  • Tall ceilings crown the foyer, while barn doors part to reveal a home office to the right. Straight ahead, the great room seamlessly connects to the eat-in kitchen, and they both extend outdoors onto the covered lanai.
  • The serene master suite provides ample space for a sitting nook and the pass-thru wardrobe leads to a 4-fixture ensuite with an oversized shower.
  • Extra space in the garage can be used as a workshop, and the sizable laundry room boasts a pet shower for your furry family members.
  • A second master suite can be found upstairs, next to a large gathering space with french doors that opens to a balcony. Two additional bedrooms on this level share a Jack-and-Jill bath.

Each plan set includes the following:

  • Foundation Plan: Complete with dimensions, dimensioned plumbing, referenced details, General Notes and Schedules.
  • Elevations: Minimal four completed elevations with dimensions, notes and material call outs. Also exterior details where applicable.
  • Floor Plan(s): Complete with dimensions and notes of all elements. On our high-end plans we provide architectural and structural floor plans, as typical part of our sets to avoid clatter and for easy construction.
  • Roof Plan: Complete with roof pitches overhangs and notes for special condition also dimensions on any special condition as per plan.
  • Building Sections: Where applicable, building sections are included. The quantity of these drawings is determined by the plan set complexity.
  • Details: Interior and Exterior details as require per plan. Common details are: Applicable Cornice (Eve) and Special Details designed directly from the plan (not typical details that are reused for every plan produced). We do this to improve the accuracy and integrity that should be expected from quality set of plans.
  • Interior Elevations: Some sets include interior Kitchen, Bathrooms and other significant detailed plan specific areas.
  • Roof Framing Plan: Engineered truss layout from a local truss company. All hangers, connectors and or special details are shown. Since local codes and conditions very, this plan is for reference only.
  • Floor Framing Plan: Only were needed. Engineered floor truss layout from a local truss company. All hangers, connectors and or special details are shown. Since local codes and conditions very, this plan is for reference only.
  • Building Sections: Complete with layout, light fixtures, outlets, legend and notes.
  • Electrical Plan: Complete with layout, Light fixtures, Outlets and legend.
  • Lintel Plan: Provided with block concrete masonry unit plans only. Lintel sizes and details for all exterior openings. Since local codes and conditions very, this plan is for reference only.
  • Structural Details: Including wall sections and all framing details needed per plans. Since local codes and conditions very, this plan is for reference only.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Transitional Country Home Plan Just Under 5,000 Square Feet - 82291KA floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Transitional Country Home Plan Just Under 5,000 Square Feet - 82291KA floor plan - 2nd Floor

Transitional Country Home Plan Just Under 5,000 Square Feet

  • 4,939

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 2

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 4,939 sq. ft.
  • 1st Floor: 2,868 sq. ft.
  • 2nd Floor: 2,071 sq. ft.

Dimensions

  • Width: 67' 8"
  • Depth: 106' 8"
  • Max ridge height: 30' 7"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 906 sq. ft.
  • Count: 3 Cars
  • Entry Location: Courtyard, Front

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): Block / CMU (main floor)

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Truss
