Two Bedroom Compact Vacation Retreat

Plan 22401DR

  • 700

    Heated s.f.

  • 2

    Beds

  • 1

    Baths

  • 1

    Stories

  • Only 20' wide, this compact Vacation house plan gives you a comfortable two bedroom retreat.
  • The 8'deep front porch has tall ceilings and decorative trim that gives it a good-looking appearance.
  • The L-shaped open layout swings around from the compact kitchen to the living area and back to the dining area.
  • Both bedrooms are at the back of the house and share the hall bathroom.
  • There's a side entry to the home as well.

Each plan includes the following:

* 4 Elevations
* Foundation Plan
* Main Floor Plan
* Upper Floor Plans (if applicable)
* Roof Plan
* Truss Diagrams & Building Section
* Construction Details
* Typical Wall Section

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
