Plan 9828SW
Versatile RV Garage Plan
Heated S.F.
800
Beds
1
Baths
1
Stories
2
Cars
2
What's Included
Plan Details
  • The oversized 18' wide by 10' high overhead garage door and 11'6" ceiling height makes this a truly versatile RV garage space.
  • The spacious open workshop has ample workbench length with numerous upper storage cabinets and is well lit with the rear facing window location.
  • The second level with vaulted ceilings is intentionally left as a blank slate to allow your personalization of this space. A shed dormer contains a bathroom conveniently located at the top of the uniquely designed staircase.
  • Plans are designed with a concrete slab foundation plan.
What's Included
  • Cover sheet with rendering
  • General notes and specifications
  • Foundation plan
  • Fully dimensioned floor plan - windows are called out as generic sizes
  • Structural floor/roof information either on the floor plans or separate framing plans for more complex designs
  • Electrical
  • Cross sections
  • Details as required
  • Elevations
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
  • Interior Cabinet Elevations or Window Schedules
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Versatile RV Garage Plan

  • 800

    Heated s.f.

  • 1

    Beds

  • 1

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 800 sq. ft.
  • 1st Floor: 110 sq. ft.
  • 2nd Floor: 690 sq. ft.

Dimensions

  • Width: 26' 0"
  • Depth: 44' 0"
  • Max ridge height: 25' 8"

Beds/Baths

  • Bedrooms: 1
  • Full bathrooms: 1

Garage

  • Type: Detached
  • Area: 624 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 11' 6" Second Floor / 8' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 4 on 12
  • Framing Type: Stick and Truss
