Plan 350048GH
1000 Square Foot Craftsman Cottage with Vaulted Living Room
Heated S.F.
1,000
Beds
1-2
Baths
2
Stories
1
Cars
1
Plan Details
  • This 1,000 sq. ft. house plan has 1 bed, 2 baths and a single-car garage (308 sq. ft.). The board and batten exterior sits above a stone skirt.
  • The vaulted living and dining room are centered between the bedrooms on the right and the kitchen and flex room on the left. Sliding doors on the back wall take you to a 10'-deep covered porch.
  • There is a stackable washer/dryer in the bedroom suite, a walk-in closet and two vanities in the bathroom. With a tub in the bathroom across the home, you could use the flex room as a second bedroom if needed.
What's Included
  • Exterior Elevations:  The exterior elevations provide exterior views of the house and call out the exterior finish materials, such as siding, stucco, brick, stone, etc. This page also shows roof pitches and materials, and decorative elements, such as columns and window shutters. Sometimes window and door sizes are also shown here.
  • Floor Plans:  The floor plan shows how each room is laid out on each floor of the house. In most cases, the floor plan will include wall sizes, room dimensions, notes about ceiling design, window and door locations and sizes, and other structural layout notes and details.
  • Foundation Plan: This page provides a detailed foundation drawing, including the thickness of the foundation walls, how the foundation is built, footing and wall placement, Rebar schedule, as well as other construction notes and details. This page may also include a floor framing plan.
  • Cross Sections: Cross sections are views from the top to the bottom of the house plan showing structural details related to the construction of the home. They will show the composition of the foundation, interior and exterior walls, roof, floor and stair details. They also show rooflines, ceiling heights, and the relationships between floors. Cross sections may be on a separate page or on various pages throughout the home plan.
  • Basic Electric: This page shows the locations of outlets, switches, and fixtures. It may be on a separate page, or located on the floor plan page.
  • Simple Plumbing: This page shows the locations of the bathtubs, showers, toilets, and sinks. This may be found on the floor plan, or it might be on a separate page.
  • Details: This page includes the structural details for the construction of the house.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

1000 Square Foot Craftsman Cottage with Vaulted Living Room

  • 1,000

    Heated s.f.

  • 1-2

    Beds

  • 2

    Baths

  • 1

    Floors

  • 1

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 1,000 sq. ft.
  • 1st Floor: 1,000 sq. ft.

Dimensions

  • Width: 52' 0"
  • Depth: 30' 0"
  • Max ridge height: 19' 4"

Beds/Baths

  • Bedrooms: 1 or 2
  • Full bathrooms: 2

Garage

  • Type: Attached
  • Area: 308 sq. ft.
  • Count: 1 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 1"

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Truss
