Plan 623145DJ 2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet

2,920 3 2.5 2 2
Print
Compare HIDE
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet

Plan 623145DJ

  • 2,920

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • This modern-style house plan was designed for an up-sloping lot and gives you a 2-car front-facing drive under garage. The ground level not only gives you parking but also storage and a large entry with a powder room, closet and built-in bench with lockers.
  • There are 2 sets of stairs in the home: one set on the lower level takes you to the main floor entry while another set takes you from the street to the covered porch with access to the entry and to the kitchen through sliding doors.
  • A formal dining room with tray ceiling is located in the front and a great room with fireplace is in the back. In-between, the kitchen with large island and huge walk-in pantry provides separation between the two spaces.
  • The top floor is where you'll find all the bedrooms and laundry. The master suite has a balcony overlooking the back, as does Bed 2. Beds 2 and 3 share a Jack and Jill bath.

Each plan set includes:


  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical Stair section
  • Cabinets are shown on all plans.

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet - 623145DJ floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet - 623145DJ floor plan - 2nd Floor

Ground Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet - 623145DJ floor plan - Ground Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 2,920 sq. ft.
  • Lower Level: 233 sq. ft.
  • 1st Floor: 1,388 sq. ft.
  • 2nd Floor: 1,299 sq. ft.
  • Porch, Combined: 175 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

  • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 32' 0"
  • Depth: 66' 0"
  • Max ridge height: 25' 7"

Garage

  • Type: Drive Under
  • Area: 437 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Architectural Style

Special features

2-Story 3-Bed Modern-Style House Plan Under 3000 Square Feet

  • 2,920

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • PDF - Single-Build $1,600
  • 5 Sets + PDF $1,850
  • PDF - Unlimited Build $2,100
  • CAD + PDF - Single-Build $2,100
  • CAD Unlimited + PDF $2,600
  • View all purchase option online

About This Plan

  • This modern-style house plan was designed for an up-sloping lot and gives you a 2-car front-facing drive under garage. The ground level not only gives you parking but also storage and a large entry with a powder room, closet and built-in bench with lockers.
  • There are 2 sets of stairs in the home: one set on the lower level takes you to the main floor entry while another set takes you from the street to the covered porch with access to the entry and to the kitchen through sliding doors.
  • A formal dining room with tray ceiling is located in the front and a great room with fireplace is in the back. In-between, the kitchen with large island and huge walk-in pantry provides separation between the two spaces.
  • The top floor is where you'll find all the bedrooms and laundry. The master suite has a balcony overlooking the back, as does Bed 2. Beds 2 and 3 share a Jack and Jill bath.

Floor Plans

  • Main Level

  • 2nd Floor

  • Ground Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,920 sq. ft.
  • Lower Level: 233 sq. ft.
  • 1st Floor: 1,388 sq. ft.
  • 2nd Floor: 1,299 sq. ft.
  • Porch, Combined: 175 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 32' 0"
  • Depth: 66' 0"
  • Max ridge height: 25' 7"

Garage

  • Type: Drive Under
  • Area: 437 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front
Plan 623145DJ
View this and more for this plan by visiting www.architechtecturaldesigns.com/623145DJ
|
