Plan 35186GH Commanding Views From Twin Covered Decks

4,104 3 3 1-2 3
Print
Compare
...
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

Commanding Views From Twin Covered Decks

Plan 35186GH

  • 4,104

    Heated s.f.

  • 3

    Beds

  • 3

    Baths

  • 1-2

    Stories

  • 3

    Cars

  • Enjoy commanding views from a pair of vaulted covered decks and inside from the two-story great room in this exciting vacation house plan. The decks provide plenty of space to sit and enjoy the views.
  • The focal point of the great room is the warm fireplace where you can relax and enjoy the views from the two-story windows. A loft with storage above shares these views.
  • Windows surround the dining room with light and close proximity to the kitchen makes serving a breeze. A door gives access to the covered side deck.
  • A large walk-in closet and a spa bath pamper the owners who also have their own access to the deck.
  • A guest room by the entry can double as a den or study. A pantry and large utility room is right off the garage.
  • The lower level is a great retreat. It features a large game room with fireplace and wet bar plus a bedroom with full bath and a mechanical room.
  • Related Plans: Save money and finish the lower level later with house plan 35156GH.

Each plan set includes the following:

  • Coversheet: This is an artist's rendering of the finished home. This is used as a visual aid, but it is not needed for construction.
  • Exterior Elevations:  The exterior elevations provide exterior views of the house and call out the exterior finish materials, such as siding, stucco, brick, stone, etc. This page also shows roof pitches and materials, and decorative elements, such as columns and window shutters. Sometimes window and door sizes are also shown here.
  • Floor Plans:  The floor plan shows how each room is laid out on each floor of the house. In most cases, the floor plan will include wall sizes, room dimensions, notes about ceiling design, window and door locations and sizes, and other structural layout notes and details.
  • Foundation Plan:This page provides a detailed foundation drawing, including the thickness of the foundation walls, how the foundation is built, footing and wall placement, Rebar schedule, as well as other construction notes and details. This page may also include a floor framing plan.
  • Cross Sections: Cross sections are views from the top to the bottom of the house plan showing structural details related to the construction of the home. They will show the composition of the foundation, interior and exterior walls, roof, floor and stair details. They also show rooflines, ceiling heights, and the relationships between floors. Cross sections may be on a separate page or on various pages throughout the home plan.
  • Interior Elevations: The interior elevations show built-in features of a house plan, such as kitchen cabinets, fireplaces, built-in bookshelves and desks, vanities, moldings, and hand rails.
  • Basic Electric:This page shows the locations of outlets, switches, and fixtures. It may be on a separate page, or located on the floor plan page.
  • Simple Plumbing: This page shows the locations of the bathtubs, showers, toilets, and sinks. This may be found on the floor plan, or it might be on a separate page.
  • Details: This page includes the structural details for the construction of the house.
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Basement

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Commanding Views From Twin Covered Decks - 35186GH floor plan - Basement

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Commanding Views From Twin Covered Decks - 35186GH floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Commanding Views From Twin Covered Decks - 35186GH floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 4,104 sq. ft.
  • Lower Level: 1,890 sq. ft.
  • 1st Floor: 1,890 sq. ft.
  • 2nd Floor: 324 sq. ft.
  • Screened Porch: 455 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 3

Foundation Type

  • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 80' 1"
  • Depth: 90' 6"
  • Max ridge height: 25' 7"

Garage

  • Type: Attached
  • Area: 947 sq. ft.
  • Count: 3 Cars
  • Entry Location: Courtyard

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof Details

  • Primary Pitch: 10 on 12
  • Secondary Pitch: N on N

Architectural Style

Special features

Plan Collections

Commanding Views From Twin Covered Decks

  • 4,104

    Heated s.f.

  • 3

    Beds

  • 3

    Baths

  • 1-2

    Floors

  • 3

    Car garage

Buy This Plan
  • 5 Sets $2,195
  • PDF + CAD - Single Build $2,295
  • 5 Sets + PDF $2,445
  • CAD + PDF - Unlimited Build $2,995
  • View all purchase option online

About This Plan

  • Enjoy commanding views from a pair of vaulted covered decks and inside from the two-story great room in this exciting vacation house plan. The decks provide plenty of space to sit and enjoy the views.
  • The focal point of the great room is the warm fireplace where you can relax and enjoy the views from the two-story windows. A loft with storage above shares these views.
  • Windows surround the dining room with light and close proximity to the kitchen makes serving a breeze. A door gives access to the covered side deck.
  • A large walk-in closet and a spa bath pamper the owners who also have their own access to the deck.
  • A guest room by the entry can double as a den or study. A pantry and large utility room is right off the garage.
  • The lower level is a great retreat. It features a large game room with fireplace and wet bar plus a bedroom with full bath and a mechanical room.
  • Related Plans: Save money and finish the lower level later with house plan 35156GH.

Floor Plans

  • Basement

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 4,104 sq. ft.
  • Lower Level: 1,890 sq. ft.
  • 1st Floor: 1,890 sq. ft.
  • 2nd Floor: 324 sq. ft.
  • Screened Porch: 455 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 3

Foundation Type

    • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 80' 1"
  • Depth: 90' 6"
  • Max ridge height: 25' 7"

Garage

  • Type: Attached
  • Area: 947 sq. ft.
  • Count: 3 Cars
  • Entry Location: Courtyard

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: N on N
