Plan 135179GRA Contemporary Barndominium-style Home Plan with L-shaped Porch

Contemporary Barndominium-style Home Plan with L-shaped Porch

Plan 135179GRA

  • 3,004

    Heated s.f.

  • 3

    Beds

  • 2.5+

    Baths

  • 2

    Stories

  • 3

    Cars

  • This 3-bed contemporary barndominium-style home plan has a porch that wraps around the front-left corner giving you great fresh-air space to enjoy. The porch is accessible from the living room (through sliding doors on two walls) and the master bedroom.
  • The garage is massive and has a 10' by 10' door for larger vehicles and a 14' by 14' door for RVs and boats. A half bath gives you a place to clean up after working on your vehicles.
  • The living room has a 2-story ceiling and is open to the kitchen and dining area. There's great storage in the butler's pantry.
  • The master bedroom has a large walk-in closet and a bath with two vanities and direct access to the laundry room.
  • Upstairs, two bedrooms each have walk-in closet and share a bathroom. A balcony overlooks the living room below and a large loft gives the kids a place to hang out outside their bedrooms.
  • Related Plans: Get an alternate version with house plans 135075GRA and 135160GRA

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Contemporary Barndominium-style Home Plan with L-shaped Porch - 135179GRA floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Contemporary Barndominium-style Home Plan with L-shaped Porch - 135179GRA floor plan - 2nd Floor

Plan details

Contemporary Barndominium-style Home Plan with L-shaped Porch

  • 3,004

    Heated s.f.

  • 3

    Beds

  • 2.5+

    Baths

  • 2

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $1,250
  • 5 Sets $1,425
  • 5 Sets + PDF $1,500
  • PDF - Unlimited Build $1,750
  • CAD + PDF - Single-Build $2,500
  • CAD - Unlimited Build $3,000
  • View all purchase option online

About This Plan

  • This 3-bed contemporary barndominium-style home plan has a porch that wraps around the front-left corner giving you great fresh-air space to enjoy. The porch is accessible from the living room (through sliding doors on two walls) and the master bedroom.
  • The garage is massive and has a 10' by 10' door for larger vehicles and a 14' by 14' door for RVs and boats. A half bath gives you a place to clean up after working on your vehicles.
  • The living room has a 2-story ceiling and is open to the kitchen and dining area. There's great storage in the butler's pantry.
  • The master bedroom has a large walk-in closet and a bath with two vanities and direct access to the laundry room.
  • Upstairs, two bedrooms each have walk-in closet and share a bathroom. A balcony overlooks the living room below and a large loft gives the kids a place to hang out outside their bedrooms.
  • Related Plans: Get an alternate version with house plans 135075GRA and 135160GRA

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 3,004 sq. ft.
  • 1st Floor: 1,710 sq. ft.
  • 2nd Floor: 1,294 sq. ft.
  • Porch, Combined: 975 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 2

Foundation Type

    • Standard Foundations: Crawl
    • Optional Foundations: Slab, Walkout, Basement

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 85' 0"
  • Depth: 55' 0"
  • Max ridge height: 27' 3"

Garage

  • Type: RV Garage, Attached
  • Area: 1665 sq. ft.
  • Count: 3 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 9' 0"

Roof

  • Primary Pitch: 4 on 12
  • Framing Type: Truss
