Plan 66130WE
Fine Olde Florida Home Plan
Heated S.F.
4,763
Beds
4
Baths
5
Stories
2
Cars
3
Floor Plan

Plan 66130WE

Main Level
slide image 0
2nd Floor
slide image 1

Plan 66130WE

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • This fine Olde Florida home plan is living at its best! All bases are covered with this floor plan. A curved staircase creates a warm welcome.
  • 4 bedrooms, 5 full baths, a library, study, music room, media room, kitchen with island, laundry room on second floor, and elevator are all features of this lovely home.
  • The wraparound porch and covered balconies are great ways to unwind when the temperatures cool.
  • This is a great house plan build, live in, entertain, and relax.
What's Included
Elevations - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Material Labels
  • Floor-to-Floor Heights
  • Roof Slope Indicators
Floor Plans - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Door and Window Sizes
  • Completely Dimensioned Floor Plan
  • Room Labels and Interior Room Sizes
Electrical Layouts
  • Building Section Markers
  • All Electrical Outlets, Fixtures, and Switching
Foundation Plan - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Floor and Deck Joist Size and Spacing
  • Electrical Locations (if applicable)

Roof Design Plan - Drawn at 1/8″ to 1/4″ = 1′-0″scale, and Includes:
  • All Beam and Header Heights and Locations
  • All Hips, Gables, Ridges, and Valleys
  • Building Section Markers
Building Sections - Drawn at 1/8″ to 1/4″ = 1′-0″ Scale, and Includes:
  • Floor Joist Size and Spacing
  • Floor-to-Floor Heights
  • Non-Typical Plate Heights Indicated
Typical Wall Sections - Drawn at 1/8″ to 1/2″ = 1′-0″ Scale, and Includes:
  • All Labels Indicating Wall Construction
  • Foundation Wall Thickness and Reinforcing
  • Insulation Type and Thickness
Miscellaneous Notes and Details
  • Miscellaneous General Notes
  • Stairway details (if applicable)
We do provide a slab plan, however, the structural foundation plan is to be provided by the structural engineer selected by your builder or yourself. This is done because our slab plan cannot anticipate the variations in soil, footings and other conditions per your specific site. We provide the design of the roof as well, however, the truss layouts need to be provided by a truss engineer or your lumber company. Your builder can provide these contacts for you.  Please keep in mind that these are additional expenses outside of the cost of the original plan that you purchase from us.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.

Square Footage Breakdown

Total Heated Area

4,763 sq. ft.

1st Floor

2,504 sq. ft.

2nd Floor

2,259 sq. ft.

Entry

316 sq. ft.

Lanai

1,090 sq. ft.

Balcony / Veranda

17 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

5

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

Block / CMU (main floor)

Optional Type(s)

2x6

Dimensions

Width

80' 4"

Depth

71' 1"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

824 sq. ft.

Count

3 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Second Floor

10'

Room

Ceiling Type

Height

Master Bath

Vaulted

11' 4''

Lanai

Flat

10' 0''

Entry

Volume

10' 8''

Foyer

Volume

10' 8''

Master Bedroom

Vaulted

11' 4''

Study

Flat

10' 0''

Dining Room

Flat

10' 0''

Kitchen

Flat

10' 0''

All Bedrooms

Flat

10' 0''

Living Room

Vaulted

22' 0''

Loft

Flat

10' 0''

Family Room

Volume

10' 8''

None

10' 8''

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Florida

Mediterranean

Special Features

Bedrooms - Split

Elevator

Laundry - Main Level

Library/Study

Master Suite - 2nd Floor

Media Room

Wrap Around Porch

Square Footage Breakdown

Total Heated Area

4,763 sq. ft.

1st Floor

2,504 sq. ft.

2nd Floor

2,259 sq. ft.

Entry

316 sq. ft.

Lanai

1,090 sq. ft.

Balcony / Veranda

17 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

5

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

Block / CMU (main floor)

Optional Type(s)

2x6

Dimensions

Width

80' 4"

Depth

71' 1"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

824 sq. ft.

Count

3 Cars

Entry Location

Front

Ceiling Heights

First Floor

10'

Second Floor

10'

Room

Ceiling Type

Height

Master Bath

Vaulted

11' 4''

Lanai

Flat

10' 0''

Entry

Volume

10' 8''

Foyer

Volume

10' 8''

Master Bedroom

Vaulted

11' 4''

Study

Flat

10' 0''

Dining Room

Flat

10' 0''

Kitchen

Flat

10' 0''

All Bedrooms

Flat

10' 0''

Living Room

Vaulted

22' 0''

Loft

Flat

10' 0''

Family Room

Volume

10' 8''

None

10' 8''

Roof Details

Primary Pitch

6 on 12

Framing Type

Truss

Architectural Style

Florida

Mediterranean

Special Features

Bedrooms - Split

Elevator

Laundry - Main Level

Library/Study

Master Suite - 2nd Floor

Media Room

Wrap Around Porch
