Plan 65715BS Tuscan Home Plan for Coastal Living

Tuscan Home Plan for Coastal Living

Plan 65715BS

  • 3,960

    Heated s.f.

  • 4

    Beds

  • 5.5

    Baths

  • 1

    Stories

  • 3

    Cars

  • Elegant coffered ceilings rest above each of the shared spaces in this Tuscan home plan, complete with character-defining clay roof tiles.
  • Both the formal living room and family room are drenched in natural lighting and provide easy access to the covered lanai that features a summer kitchen.
  • The square-shaped kitchen hosts a central prep island with a bar sink and is surrounded by cabinets, counters, and appliances, along with a corner pantry.
  • The right wing of the layout presents a study, single garage bay, and the master suite; a spacious and private domain for the homeowner to enjoy.
  • Three additional bedrooms line the left side, along with a double garage and laundry room.

Plans include the following:


Elevations:

Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

  • Material Labels
  • Floor-To-Floor Heights
  • Roof Slope Indicators

Floor Plans:
Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

  • Door and Window Sizes
  • Completely Dimensioned Floor Plan
  • Room Labels and Interior Room Sizes

Electrical Layouts:

  • Building Section Markers
  • All Electrical Outlets, Fixtures and Switching

Foundation or Slab Plan:
Drawn at 1/8″ to 1/4″ = 1’0″ Scale

Roof Design Plan:
Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

  • All Beam and Header Heights and Locations
  • All Hips, Gables, Ridges and Valley
  • Building Section Markers

Building Sections:
Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

  • Floor-To-Floor Heights
  • Non-Typical Plate Heights Indicated

Typical Wall Sections:
Drawn at 1/8″ to 1/2″ = 1’0″ Scale and Includes:

  • All Labels Indicating Wall Construction
  • Foundation Wall Thickness
  • Insulation Type and Thickness

Miscellaneous Notes and Details:

  • Miscellaneous General Notes
  • Stairway Details (if applicable)
IMPORTANT NOTE:  Structural drawings, as well as heating and plumbing details, will not be included in your plan sets due to a variety of factors which include local codes, installation methods, personal preference, etc.  Your building professional (contractor/builder/supplier) can, without difficulty, supply these details and specifications on your behalf.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Tuscan Home Plan for Coastal Living - 65715BS floor plan - Main Level

Plan details

Tuscan Home Plan for Coastal Living

  • 3,960

    Heated s.f.

  • 4

    Beds

  • 6

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • CAD + PDF - Single-Build $3,565
  • PDF - Single-Build $3,565
  • View all purchase option online

About This Plan

  • Elegant coffered ceilings rest above each of the shared spaces in this Tuscan home plan, complete with character-defining clay roof tiles.
  • Both the formal living room and family room are drenched in natural lighting and provide easy access to the covered lanai that features a summer kitchen.
  • The square-shaped kitchen hosts a central prep island with a bar sink and is surrounded by cabinets, counters, and appliances, along with a corner pantry.
  • The right wing of the layout presents a study, single garage bay, and the master suite; a spacious and private domain for the homeowner to enjoy.
  • Three additional bedrooms line the left side, along with a double garage and laundry room.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 3,960 sq. ft.
  • 1st Floor: 3,960 sq. ft.
  • Lanai: 521 sq. ft.
  • Porch, Front: 98 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 5
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): Block / CMU (main floor)
  • Optional Type(s): 2x6

Dimensions

  • Width: 112' 4"
  • Depth: 74' 8"
  • Max ridge height: 25' 8"

Garage

  • Type: Attached
  • Area: 877 sq. ft.
  • Count: 3 Cars

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Truss
