Plan 666079RAF
Modern Northwest House Plan with Second-Level Master
Heated S.F.
3,996
Beds
5
Baths
4.5
Stories
2
Cars
3
Floor Plan

Plan 666079RAF

Main Level
slide image 0
2nd Floor
slide image 1

Plan 666079RAF

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
2nd Floor
floor plan image 2nd Floor
Plan Details
  • The exterior of this modern, Northwest house plan is comprised of oversized windows, stone, and stucco. The combination of a low-pitched, hip and valley and flat roof complete the design.
  • Inside, the formal entry and family access from the 3-car, tandem garage merge in the foyer, where tall ceilings provide a grand first impression.
  • The fireplace serves as a focal point in the great room, which is surrounded by windows to maximize access to natural light. The adjoining dining room leads to an open kitchen, with a large island that overlooks the back patio.
  • A guest suite with a full bath completes the first floor.
  • The largest of the four, second-level bedrooms is reserved for the homeowner, and boasts a luxurious bath with a freestanding tub serving as an art installation. Down the hall, three good-sized bedrooms share a compartmentalized bath.
What's Included
  • Cover Sheet with plan info
  • General Notes - Note: codes will not include local state adopted amendments
  • Fully dimensions and detailed floor plans
  • Elevations
  • Building Cross Section
  • Roof Plan
  • Details
  • Window Schedule
  • Original Structural plan FOR REFERENCE ONLY
What's Not Included
  • Architectural or Engineering Stamp  - handled locally when required
  • Site plans - handled locally - handled locally when required
  • Mechanical Drawings - handled locally when required
  • Plumbing Drawings  - handled locally when required
  • Electrical Drawings  - handled locally when required
  • Energy Calculations  - handled locally when required
  • Foundation and Framing plans  - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

3,996 sq. ft.

1st Floor

1,910 sq. ft.

2nd Floor

1,976 sq. ft.

Porch, Front

46 sq. ft.

Entry

16 sq. ft.

Covered Patio

265 sq. ft.

Beds/Baths

Bedrooms

5

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

57' 0"

Depth

59' 0"

Max Ridge Height

28' 0"

Garage

Type

Attached

Area

727 sq. ft.

Count

3 Cars

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Framing Type

Stick

Architectural Style

Contemporary

Square Footage Breakdown

Total Heated Area

3,996 sq. ft.

1st Floor

1,910 sq. ft.

2nd Floor

1,976 sq. ft.

Porch, Front

46 sq. ft.

Entry

16 sq. ft.

Covered Patio

265 sq. ft.

Beds/Baths

Bedrooms

5

Full bathrooms

4

Half bathrooms

1

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

57' 0"

Depth

59' 0"

Max Ridge Height

28' 0"

Garage

Type

Attached

Area

727 sq. ft.

Count

3 Cars

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Framing Type

Stick

Architectural Style
