Plan 135197GRA One-Story 3-Bed House Plan Under 2500 Square Feet with Drive-Under Garage

2,455 3 2 1 3
Print
Compare
...
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

One-Story 3-Bed House Plan Under 2500 Square Feet with Drive-Under Garage

Plan 135197GRA

  • 2,455

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Stories

  • 3

    Cars

  • This one-story house plan gives you 2,455 square feet of heated living space with 3 bedrooms clustered together and an unfinished basement with a drive-under garage on the right.
  • The central living space is completely open with a formal sitting room near the foyer, and a cathedral ceiling offers a cohesive element above the adjoining great room and eat-in kitchen.
  • The kitchen island includes a flush eating bar, and sliding doors on the rear wall lead to a 10'-deep grilling porch.
  • Three bedrooms occupy the left side of the design, including the master bedroom with a large picture window providing rearward views.
  • A double garage with matching 10' by 8' overhead doors is on the right side of the home and includes a safe room and a rec area.
  • There is a drive-under garage accessible from the left with a 9' by 7' garage door.
  • Related Plan: Remove the basement with house plan 135084GRA.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
One-Story 3-Bed House Plan Under 2500 Square Feet with Drive-Under Garage - 135197GRA floor plan - Main Level

Unfinished Lower Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
One-Story 3-Bed House Plan Under 2500 Square Feet with Drive-Under Garage - 135197GRA floor plan - Unfinished Lower Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 2,455 sq. ft.
  • 1st Floor: 2,455 sq. ft.
  • Porch, Combined: 565 sq. ft.
  • Basement Unfinished: 2,488 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 88' 0"
  • Depth: 66' 0"
  • Max ridge height: 24' 0"

Garage

  • Type: Drive Under, Attached
  • Area: 1388 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof Details

  • Primary Pitch: 5 on 12
  • Secondary Pitch: 9 on 12
  • Framing Type: Truss

Architectural Style

Special features

One-Story 3-Bed House Plan Under 2500 Square Feet with Drive-Under Garage

  • 2,455

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $1,150
  • 5 Sets $1,300
  • 5 Sets + PDF $1,400
  • PDF - Unlimited Build $1,650
  • CAD + PDF - Single-Build $2,200
  • CAD - Unlimited Build $2,700
  • View all purchase option online

About This Plan

  • This one-story house plan gives you 2,455 square feet of heated living space with 3 bedrooms clustered together and an unfinished basement with a drive-under garage on the right.
  • The central living space is completely open with a formal sitting room near the foyer, and a cathedral ceiling offers a cohesive element above the adjoining great room and eat-in kitchen.
  • The kitchen island includes a flush eating bar, and sliding doors on the rear wall lead to a 10'-deep grilling porch.
  • Three bedrooms occupy the left side of the design, including the master bedroom with a large picture window providing rearward views.
  • A double garage with matching 10' by 8' overhead doors is on the right side of the home and includes a safe room and a rec area.
  • There is a drive-under garage accessible from the left with a 9' by 7' garage door.
  • Related Plan: Remove the basement with house plan 135084GRA.

Floor Plans

  • Main Level

  • Unfinished Lower Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 2,455 sq. ft.
  • 1st Floor: 2,455 sq. ft.
  • Porch, Combined: 565 sq. ft.
  • Basement Unfinished: 2,488 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Walkout

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 88' 0"
  • Depth: 66' 0"
  • Max ridge height: 24' 0"

Garage

  • Type: Drive Under, Attached
  • Area: 1388 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 5 on 12
  • Secondary Pitch: 9 on 12
  • Framing Type: Truss
