Rear Sloping Lot Plan with Creative Stonework

Plan 69095AM

  • 3,651

    Heated s.f.

  • 4

    Beds

  • 3.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • Behind the striking combination of this home plan's random stack stonework and geometric windows is a hard-working four-bedroom home that forgives a lot that slopes to the side and rear.
  • Square windows interspersed on the fa'ade provide exciting visual interest from the curb, and bring much desired light to the interior. The main level feels especially light and airy thanks to a band of second-story windows beneath the upper roofline. The light floods the core of the main level where the staircase and great room meet, and spills into the neighboring kitchen and dining room. Secluded behind a set of French doors, the office gains its own light from tall corner windows.
  • Three of the home's four bedrooms are on the upper level. The master suite includes a private balcony, and a bath with a walk-in shower, a dual-sink vanity, and a private commode. The other two bedrooms are down the hall from a laundry room and a full bath.
  • The lower-level features several spaces to customize. An exercise niche and walk-in wine closet accompany a large game room. A hallway secludes a bathroom, bedroom, and utility room. A storage shed accessible from the backyard, can store tools, potting supplies, and outdoor equipment.
  • Related Plans: Building in reverse? See house plan 69096AM and 69097AM.

Exterior Elevations: In addition to the front exterior, your drawing set will include drawings of the rear and sides of your house as well. These drawings give notes on exterior materials and finishes. Particular attention is given to cornice detail, brick and stone accents, or other finish items that make your home unique.

Foundation Plan: The foundation page dimensions, concrete walls, footings, pads, posts, beams, bearing walls, and any stepped foundation information along with any retaining wall info (schematic only). A typical wall section for the home is also usually included on this page (if not, it is elsewhere in your plan set, as space allows). If your plan features a poured concrete slab rather than a basement or crawlspace, the foundation page shows footings and details for the slab, and includes plumbing locations.

Floor Plan(s): Exterior and interior wall framing, and windows/doors are dimensioned. Room sizes are indicated and any beams, posts and structural bearing points are called out. The floor plans include an electrical legend, and electrical fittings, lights and outlets are shown. Floor Plans will also indicate cross–section details (provided on the sections page) and show any special framing details applicable to the design. Cabinet elevations are included for kitchen and bathrooms; some designs feature cabinet elevations for design–related built–ins too.

Building Sections: Building sections show changes in floor, ceiling, or roof height, and the relationship of one level to another. Our section pages also show how the stairs are calculated (if there are some!) and depict roof and foundation members. We try and draw sections to show the most useful information — choosing locations where there are elements you or your contractor might need clarification on.

IMPORTANT NOTE:  Sections and elevations depict the standard foundation only.

Roof Plan: Roof framing or truss directions are shown, slope directions are indicated and structural members are sized and called out if applicable. The gravity loads used to calculate the rafters, beams and posts are indicated , and we also show gutters, downspouts, and any roof venting required for your home.

Notes and Details Page(s): Your home comes detailed to meet the requirements of the latest adopted version of the ‘International Residential Code’, and our notes and details pages outline all the elements applicable to the design of your home. Compliance with further standards may need to be incorporated into your plan set, depending on the requirements of your building department — these are usually done locally.


These items are NOT included:


  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
