Exclusive Transitional Craftsman with Office and Bonus Room
Heated S.F.
3,923
Beds
4
Baths
4.5
Stories
2
Cars
2
What's Included
Plan Details
  • This thoughtful and functional design with a Transitional Craftsman exterior provides just under 4,000 square feet of living space and is exclusive to Architectural Designs.
  • The seamless connection between the family room and lanai is perfect outdoor living, while the island kitchen boasts plenty of workspace, a large range, and scullery.
  • The master suite serves as a true oasis for the homeowner with its vaulted ceiling, deluxe ensuite, and stackable washer / dryer in the master closet.
  • Three good-sized bedroom suites can be found upstairs, along with a home office and flexible bonus room with a wet bar and additional closet space.
  • A toy garage bay is attached to the double garage and built-in cubbies in the mudroom helps to organize bags, shoes, and outerwear.
  • Related Plans: Get an alternate version with house plans 93140EL, 93142EL and 93145EL.
  • DELIVERY NOTE: Please allow 5 to 7 business days for delivery.
What's Included

  • Cover Sheet
  • General Note Sheet
  • Foundation Sheet
  • First Floor Plan
  • Second Floor Plan (if applicable)
  • Roof Framing Plan
  • Front & Rear Elevation
  • Left & Right Elevation
  • Openings & Sections Sheet
  • Foundation Details
  • Cornice Details
  • First Floor Electrical
  • Second Floor Electrical (if applicable)

What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Exclusive Transitional Craftsman with Office and Bonus Room

  • 3,923

    Heated s.f.

  • 4

    Beds

  • 4.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 3,923 sq. ft.
  • 1st Floor: 1,957 sq. ft.
  • 2nd Floor: 1,966 sq. ft.

Dimensions

  • Width: 57' 8"
  • Depth: 85' 4"
  • Max ridge height: 34' 0"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 678 sq. ft.
  • Count: 2 Cars
  • Entry Location: Courtyard

Foundation Type

    • Standard Foundations: Crawl
    • Optional Foundations: Basement, Slab, Walkout

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"
